SImplify calibration process
An operator can directly check the printings via the HMI. Instead of checking the finished product or using a stroboscope, showing the result on the screen is more intuitive and time-saving.
Make your printing inspection much easier
01. Main FEATURES
Why DO you need an AOI Cable printer?
An AOI printer suits you well when you need to print the cables. But it can give you more if you need to run your production lines faster.
Record all the flaws
Once detecting any flaws in production, the system records the flaws data in the resume --- time, pictures, and location. QC department can pick out the problematic segments effortlessly with it.
02. Benefits
AOI system is a solution FOR improving Printing inspection
An AOI system can break the restriction of the human eye and save spending from various aspects. It contains three benefits you should try out.
Time and Material saving
If flaws are detected, the printer will alert the operators with the tricolored light. This design prevents the printer from continuously outputting the cable with printing defects without notice. Also, the QC department spends less time finding flaws in the finished product by looking up the production resumes.
Treat your operators well
Your employees are your most valuable assets. For operators, this printer makes the inspection more effortless with a screen showing the printing. It also eliminates the sore-eye problem, while operators use a stroboscope to capture the prints on the moving cable.
IOt ready
As an IoT-ready machine, the AOI cable printer can realize distance monitoring by connecting to the Smart Factory platform. You can check the manufacturing info with your devices, such as laptops, tablets, or smartphones.
03. interface
The user interface of AOI cable printer
04. Pictures
AOI cable printer in exhibition
In Düsseldorf
IN Kaohsiung
AOI printer
in exhibition
06. specification
SPecification of AOI cable printer
| Model name | PRT-SH500/1000 | |
| Application | High speed printing | |
| Wire range | Ø0.3 - Ø9 mm | |
| Line speed | < 500 M/min (PRT-SH500) < 1000 M/min (PRT-SH1000) | |
| Printing head | 1 unit | |
| Driven motor | Non Motor (PRT-SH500) 200W Servomotor (PRT-SH1000) | |
| Wheel size | Ø100 mm x 10 mm | |
| Ink pump | Air pump | |
| Ink pump speed | Auto adjustment according to speed | |
| Pneumatic air supply | > 3bar | |
| Dimension | 700mm x 1250mm x 630mm | |
| Power supply | 220VAC 50/60Hz |
| Model name | PRT-SH500/1000 | |
| Application | High speed printing | |
| Wire range | Ø0.3 - Ø9 mm | |
| Line speed | < 500 M/min (PRT-SH500) < 1000 M/min (PRT-SH1000) | |
| Printing head | 1 unit | |
| Driven motor | Non Motor (PRT-SH500) 200W Servomotor (PRT-SH1000) | |
| Wheel size | Ø100 mm x 10 mm | |
| Ink pump | Air pump | |
| Ink pump speed | Auto adjustment according to speed | |
| Pneumatic air supply | > 3bar | |
| Dimension | 700mm x 1250mm x 630mm | |
| Power supply | 220VAC 50/60Hz |
06. Contact
Get YOUR QUOTE
PIoneer Machinery
Pioneer Machinery, founded in 1973, is a well-known wire and cable machinery supplier worldwide. Besides our headquarter in Taiwan, our departments locate in Europe, America, and Brazil, otherwise agencies all over the world.
